Siemens RX1500

RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring L2TPv3 Tunnels 645
1
2
3
Figure 756: Local Cookie Form
1. Size Selection Box 2. Low Value Field 3. High Value Field
1
2
3
Figure 757: Remote Cookie Form
1. Size Selection Box 2. Low Value Field 3. High Value Field
9. On the Static L2TPv3 Sessions form, configure the following parameter(s) as required:
Parameter Description
enabled Default: true
Enables/Disables the session
local-session-id The local session-id provides the necessary context for all further packet processing
remote-session-id The remote session-id is used to identify the received data messages from remote
session endpoint
mtu Default: 1488
MTU of network interface
10. On the Local Cookie form, configure the following parameter(s) as required:
