RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Configuring QoS Marking 779
Figure 893: Mark Choice Save Form
1. Value Mask Box 2. Operation Chain List
2. Configure the following parameter(s) as required:
Parameter Description
value-mask Mask to process the mark with
op-chain Synopsis: forward, prerouting
Default: forward
A chain in which the operation will take place.
Configuring a Restore Mark
1. In the menu, click restore. The Mark Choice Restore form appears.
Figure 894: Mark Choice Restore Form
1. Value Mask Box 2. Operation Chain List
2. Configure the following parameter(s) as required:
Parameter Description
value-mask A mask to process the mark with.
op-chain Synopsis: forward, prerouting
Default: forward
A chain in which the operation will take place.
