The internal shunt and maximum current parameter pairs are defined as described in
the table below.
Parameter Internal shunt Maximum current
A100r01
10 A 10 mΩ
A40R01
4.5 A 10 mΩ
A45M10r
45 mA 10 Ω
A4M510r
4.5 mA 10 Ω
A45u10k
45 µA 10 KΩ
A4U510k
4.5 µA 10 KΩ
Suffix:
<m>
.
1..2
<n> 1..4
Parameters:
<IntShuntMeasRg> A100r01 | A40R01 | A45M10r | A4M510r | A45u10k | A4U510k
*RST: A100r01
Usage: Asynchronous command
ZVC:Z<m>:I<n>:SHUNt:MXCValue?
Queries the maximum current.
Suffix:
<m>
.
1..2
<n> 1..4
Return values:
<MaxCurrentValue> Default unit: A
Usage: Query only
Asynchronous command
ZVC:Z<m>:I<n>:SHUNt:MAXVoltage <ExtShuntMeasRg>
Sets the maximum voltage for the external shunt.
Suffix:
<m>
.
1..2
<n> 1..4
