Remote control commands
R&S
®
RTE
1143User Manual 1326.1032.02 ─ 20
PROBe<m>:SETup:ADAPter?
Queries the adapter status, whether the instrument identified the adapter.
Suffix:
<m>
.
1..4
Selects the input channel.
Return values:
<Type> NONE | Z2T
*RST: NONE
Usage: Query only
Asynchronous command
PROBe<m>:SETup:ATTenuation:TDEFprobe
<TekPredefProbe>
Selects the Tektronics probe that is connected to the R&S RT‑Z2T adapter.
Suffix:
<m>
.
1..4
Parameters:
<TekPredefProbe> NONE | P5205A50 | P5205A500 | P5210A100 | P5210A1000 |
P6205 | P6241 | P6243 | P6245 | P6246A1 | P6246A10 |
P6247A1 | P6247A10 | P6248A1 | P6248A10 | P6249 |
P6250A5 | P6250A50 | P6251A5 | P6251A50 | P6701B |
P6703B | P6711 | P6713 | TCP202
*RST: NONE
Example:
PROBe2:SETup:ADAPter
<-- Z2T
PROBe2:SETup:ATTenuation:TDEFprobe P5205A50
Checks the adapter state on channel 2, and selects the probe
P5205A50.
Usage: Asynchronous command
18.8.8 R&S RT-ZVC probe
● Probe setup.........................................................................................................1143
● Resolution and data............................................................................................ 1155
18.8.8.1 Probe setup
In the ZVC:Z<m>: commands, the following suffixes are used:
●
<m> selects the multi-channel probe. The available range is 1..2
●
<n> selects the voltage or current channel. The available range depends on the
probe characteristics and is 1..2 or 1..4
Acquisition and setup
