Parameters:
<Pattern> Numeric or string pattern, see Chapter 18.4.6, "Bit pattern
parameter", on page 1076. The string parameter accepts the bit
value X (don't care).
Usage: Asynchronous command
TRIGger<m>:SPATtern:REFSource <ReferenceSource>
Selects if an explicit clock or a CDR signal is used as a reference signal.
Suffix:
<m>
.
1..3
Parameters:
<ReferenceSource> CDR | CLOCk
*RST: CDR
Usage: Asynchronous command
18.9.14 TV/Video trigger
The TV or video trigger requires a channel input as trigger source (TRIGger<m>:
SOURce[:SELect]). It is only available for the A-event (Suffix = 1).
Make sure to set the trigger level - the threshold of the sync pulse - with TRIGger<m>:
LEVel<n>[:VALue].
TRIGger<m>:TV:STANdard...........................................................................................1192
TRIGger<m>:TV:MODE................................................................................................ 1193
TRIGger<m>:TV:POLarity............................................................................................. 1194
TRIGger<m>:TV:LINE...................................................................................................1194
TRIGger<m>:TV:LFIeld.................................................................................................1195
TRIGger<m>:TV:CUSTom:SCANmode...........................................................................1195
TRIGger<m>:TV:CUSTom:LDURation............................................................................ 1196
TRIGger<m>:TV:CUSTom:STYPe..................................................................................1196
TRIGger<m>:TV:CUSTom:SDURation............................................................................1196
TRIGger<m>:TV:STANdard <Standard>
Sets the TV standard.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
Parameters:
<Standard> CUSTom | PAL | PALM | NTSC | SECam | P480L60HZ |
P720L30HZ | P720L50HZ | P720L60HZ | I1080L50HZ |
I1080L60HZ | P1080L24HZ | P1080L24HZSF | P1080L25HZ |
P1080L30HZ | P1080L50HZ | P1080L60HZ
