Remote control commands
R&S
®
RTE
1195User Manual 1326.1032.02 ─ 20
Standard Minimum value Maximum value
720p/30 (P720L30HZ)
720p/50 (P720L50HZ)
720p/60 (P720L60HZ)
1 750
1080i/50 (I1080L50HZ)
1080i/60 (I1080L60HZ)
1080p/24 (P1080L24HZ)
1080p/24sF (P1080L24HZSF)
1080p/25 (P1080L25HZ)
1080p/30 (P1080L30HZ)
1080p/50 (P1080L50HZ)
1080p/60 (P1080L60HZ)
1 1125
TRIGger<m>:TV:LFIeld <LineField>
The commands is only relevant for NTSC signals and sets the field in which the line
number is counted.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
Parameters:
<LineField> FIELD1 | FIELD2
FIELD1 = odd field
FIELD2 = even field
*RST: FIELD1
Usage: Asynchronous command
TRIGger<m>:TV:CUSTom:SCANmode <ScanMode>
Sets the scanning system. Only relevant if TRIGger<m>:TV:STANdard is set to
CUSTom.
See also: "Scan" on page 263.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
Parameters:
<ScanMode> INTerlaced | PROGressive | SEGMented
SEGMented: Progressive segmented frame uses progressive
scanning to capture the frame, and interlaced scanning for trans-
mission and display.
*RST: INTerlaced
Usage: Asynchronous command
Trigger
