SEARch:TRIGger:GLITch:RANGe <SearchName>,<RangeMode>
SEARch:TRIGger:GLITch:RANGe? <SearchName>
Selects which glitches are identified: shorter or longer than the specified width (see
SEARch:TRIGger:GLITch:WIDTh on page 1357).
Parameters:
<RangeMode> SHORter | LONGer
*RST: SHORter
Parameters for setting and query:
<SearchName> Search definition
Usage: Asynchronous command
SEARch:TRIGger:GLITch:WIDTh <SearchName>,<Width>
SEARch:TRIGger:GLITch:WIDTh? <SearchName>
Sets the length of a glitch. The instrument triggers on pulses shorter or longer than this
value (see also SEARch:TRIGger:GLITch:RANGe on page 1357).
You need to know the expected pulse widths of the circuit to set the glitch width cor-
rectly.
Parameters:
<Width> Range: 100E-12 to 1E-3
Increment: 100E-6
*RST: 1E-9
Default unit: s
Parameters for setting and query:
<SearchName> Search definition
Usage: Asynchronous command
18.15.5 Interval search conditions
Trigger level setting: SEARch:TRIGger:LEVel[:VALue] on page 1355
SEARch:TRIGger:INTerval:SLOPe.................................................................................1357
SEARch:TRIGger:INTerval:DELTa..................................................................................1358
SEARch:TRIGger:INTerval:RANGe................................................................................1358
SEARch:TRIGger:INTerval:WIDTh.................................................................................1359
SEARch:TRIGger:INTerval:SLOPe <SearchName>,<Slope>
SEARch:TRIGger:INTerval:SLOPe? <SearchName>
Sets the edge for the search.
