Remote control commands
R&S
®
RTE
1672User Manual 1326.1032.02 ─ 20
SEARch:RESult:ETHernet:WORD<m>:BYTE<n>:VALue? <SearchName>
BYTE returns all data of up to 1982 bytes (not just the first 5 or 6 bytes). This is also
visible in the data table under "Show details".
Suffix:
<m>
.
*
<n> *
Selects the byte number.
Query parameters:
<SearchName> String parameter
Return values:
<FrameByteValue> Range: 0 to 255
Increment: 1
*RST: 0
Usage: Query only
18.17.13 Ethernet 100BASE-T1 (option R&S RTE-57)
● Configuration.......................................................................................................1672
● Trigger.................................................................................................................1676
● Decode results.................................................................................................... 1683
● Search settings................................................................................................... 1689
● Search results..................................................................................................... 1697
18.17.13.1 Configuration
In all BUS<m>:HBTO commands, the suffix <m> selects the serial bus.
BUS<m>:HBTO:ATTN.................................................................................................. 1672
BUS<m>:HBTO:FDAM................................................................................................. 1673
BUS<m>:HBTO:FDAP..................................................................................................1673
BUS<m>:HBTO:FDIF................................................................................................... 1673
BUS<m>:HBTO:FTYP..................................................................................................1674
BUS<m>:HBTO:RDAM.................................................................................................1674
BUS<m>:HBTO:RDAP................................................................................................. 1674
BUS<m>:HBTO:RDIF...................................................................................................1674
BUS<m>:HBTO:RTYP..................................................................................................1674
BUS<m>:HBTO:THReshold.......................................................................................... 1675
BUS<m>:HBTO:POLarity..............................................................................................1675
BUS<m>:HBTO:MODE.................................................................................................1675
BUS<m>:HBTO:SYMRate.............................................................................................1675
BUS<m>:HBTO:ATTN <Attenuation>
Sets the attenuation factor. It is used to de-amplify the reverse signal before subtract-
ing it from the forward signal.
Protocols
