TEN
10/50/90
TWENty
20/50/80
USER
Set the reference levels to individual values with
REFLevel<m>:RELative:LOWer, REFLevel<m>:
RELative:MIDDle, and REFLevel<m>:RELative:UPPer.
Example:
REFL2:REL:MODE FIVE
Reference levels for Ch1: Lower reference level = 5% of high
signal level, middle reference level = 50% of high signal level,
upper reference level = 95% of high signal level
Example: See: "Manual reference level definition using relative values"
on page 1057
Usage: Asynchronous command
18.12.13.2
Automatic configuration
REFLevel<m>:AUTO[:STATe]........................................................................................1310
REFLevel<m>:AUTO:COUNt........................................................................................ 1310
REFLevel<m>:AUTO[:STATe] <Value>
Enables averaging over several histograms to determine the reference levels. The
number of histograms to consider is defined using REFLevel<m>:AUTO:COUNt.
This function is only available in automatic reference level mode (see REFLevel<m>:
LDETection on page 1309).
Suffix:
<m>
.
Valid suffix numbers: 2 to 21, 61 to 68, 108 to 111, 115 to 118
Source waveform of the measurement, see Chapter 18.4.1,
"Waveform suffix", on page 1072.
Parameters:
<Value> ON | OFF
Usage: Asynchronous command
REFLevel<m>:AUTO:COUNt <Value>
Defines the number of histograms from which the average is calculated.
Suffix:
<m>
.
Valid suffix numbers: 2 to 21, 61 to 68, 108 to 111, 115 to 118
Source waveform of the measurement, see Chapter 18.4.1,
"Waveform suffix", on page 1072.
Parameters:
<Value>
