18.17.16.3 Decode results
In all BUS<m>:MDIO:WORD<n> commands, the suffix <m> selects the serial bus and
the suffix <n> selects the word number in the decode table.
BUS<m>:MDIO:WCOunt?.............................................................................................1781
BUS<m>:MDIO:WORD<n>:DATA?................................................................................ 1781
BUS<m>:MDIO:WORD<n>:PHYS?............................................................................... 1781
BUS<m>:MDIO:WORD<n>:REGI?................................................................................ 1782
BUS<m>:MDIO:WORD<n>:ST?.................................................................................... 1782
BUS<m>:MDIO:WORD<n>:STARt?...............................................................................1782
BUS<m>:MDIO:WORD<n>:STATe?............................................................................... 1783
BUS<m>:MDIO:WORD<n>:STOP?................................................................................1783
BUS<m>:MDIO:WORD<n>:SYMBol?.............................................................................1784
BUS<m>:MDIO:WORD<n>:TYPE?................................................................................1784
BUS<m>:MDIO:WCOunt?
Returns the word count for the selected serial bus, i.e. the number of words in the
present acquisition.
Suffix:
<m>
.
1..4
Return values:
<FrameCount> Range: 0 to 100000
Increment: 1
*RST: 0
Usage: Query only
BUS<m>:MDIO:WORD<n>:DATA?
Returns the 16-bit payload data field content (in Clause 22 or Clause 45), or the 16-bit
address field content (in Clause 45, only) in the present acquisition of the selected
word and the selected serial bus. The most significant bit (MSB) is transmitted first.
Suffix:
<m>
.
1..4
<n> *
Return values:
<Data>
Usage: Query only
BUS<m>:MDIO:WORD<n>:PHYS?
Returns the 5-bit address field content (PHYAD/PRTAD) in the present acquisition of
the selected word and the selected serial bus.
