Remote control commands
R&S
®
RTE
1439User Manual 1326.1032.02 ─ 20
<n> *
Selects the frame.
Return values:
<RWBitStart> Range: -100E+24 to 100E+24
*RST: 0
Default unit: s
Usage: Query only
BUS<m>:I2C:FRAMe<n>:STATus?
Returns the overall state of the frame.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
Return values:
<FrameState> INComplete | OK | UNEXpstop | INSufficient | ADDifferent
INComplete
The stop bit is missing.
OK
The frame is valid.
UNEXpstop
A stop bit was detected but clock and data are continued.
INSufficient
The frame is not completely contained in the acquisition. The
acquired part of the frame is valid.
ADDifferent
Error in 10 bit address. In case of a read access on a 10 bit
address, the first address byte is sent twice, first as write, the
second as read. The first seven bits of the byte must be identi-
cal. If they are not identical, the ADDiffernt error is indicated.
*RST:
OK
Usage: Query only
BUS<m>:I2C:FRAMe<n>:STARt?
Returns the start time of the specified frame.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
Protocols
