Remote control commands
R&S
®
RTE
1472User Manual 1326.1032.02 ─ 20
SEARch:TRIGger:SPI:FCONdition <SearchName>,<DataOperator>
SEARch:TRIGger:SPI:FCONdition? <SearchName>
Selects the operator for the data pattern: equal or not equal.
Parameters:
<DataOperator> EQUal | NEQual
*RST: EQUal
Parameters for setting and query:
<SearchName>
Firmware/software: FW 3.30
SEARch:TRIGger:SPI:MISopattern <SearchName>,<MISOPattern>
SEARch:TRIGger:SPI:MISopattern? <SearchName>
SEARch:TRIGger:SPI:MOSipattern <SearchName>,<MOSIPattern>
SEARch:TRIGger:SPI:MOSipattern? <SearchName>
Specifies a data pattern for the MISO or MOSI line, respectively.
Parameters:
<MISOPattern>
<MOSIPattern>
Numeric or string pattern, see Chapter 18.4.6, "Bit pattern
parameter", on page 1076.
Parameters for setting and query:
<SearchName>
Usage: Asynchronous command
Firmware/software: FW 3.30
SEARch:TRIGger:SPI:DPOPerator <SearchName>,<DataPosOperator>
SEARch:TRIGger:SPI:DPOPerator? <SearchName>
Operator for the data position. You can define an exact position, a position range, or let
the position undefined (ANY).
Parameters:
<DataPosOperator> ANY | OFF | EQUal | GETHan | INRange | RANGe
ANY = OFF, INRange = RANGe
*RST: ANY
Parameters for setting and query:
<SearchName>
Firmware/software: FW 3.30
Protocols
