Remote control commands
R&S
®
RTE
1503User Manual 1326.1032.02 ─ 20
Return values:
<NDBytes> Range: 1 to 64
Increment: 1
*RST: 1
Usage: Query only
Firmware/software: FW 3.35
BUS<m>:CAN:FRAMe<n>:STARt?
BUS<m>:CAN:FRAMe<n>:STOP?
Return the start time and stop time of the selected frame.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
Return values:
<Start>, <Stop> Time
Range: -100E+24 to 100E+24
*RST: 0
Default unit: s
Usage: Query only
BUS<m>:CAN:FRAMe<n>:SYMBol?
Returns the symbolic label of the specified frame if the label list is enabled.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the number of the frame in the current acquisition, 1...n.
Return values:
<Label> String with symbolic label of the identifier
Example:
BUS:CAN:FRAMe:SYMBol?
Response: Temperature
Usage: Query only
BUS<m>:CAN:FRAMe<n>:TYPE?
Returns the frame type of the selected frame.
Protocols
