Parameters:
<ThresholdStrobe> Range: -10 to 10
Increment: 0.1
*RST: 1.25
Default unit: V
BUS<m>:SWIRe:SYSLect <SyncSelector>
Selects the mode for the synchronisation settings, i.e i.e. packet align.
Suffix:
<m>
.
1..4
Parameters:
<SyncSelector> AUTO | MANual
*RST: AUTO
BUS<m>:SWIRe:COUPling <ThresCpl>
Enables coupling, i.e. the same threshold and hysteresis value is used for the strob
and the data signal.
Suffix:
<m>
.
1..4
Parameters:
<ThresCpl> ON | OFF
*RST: ON
BUS<m>:SWIRe:PRESet <ThresholdPreset>
Prests the threshold and hysteresis value of the strobe and data signal.
Suffix:
<m>
.
1..4
Parameters:
<ThresholdPreset> V25 | V165 | V125 | V09 | V12 | V0 | MANual
V25: 2.5 V (CMOS 5.0 V)
V165: 1.65 V (CMOS 3.5 V)
V125: 1.25 V (CMOS 1.5 V)
V09: 2.5 V (CMOS 1.8V)
V12: 1.2 V (LVDS single ended)
V0: 0 V (LVDS differential)
MANual: user-defined value
*RST: V12
