Remote control commands
R&S
®
RTE
1954User Manual 1326.1032.02 ─ 20
POWer:INRush:EXECute
Starts the inrush current measurement.
Usage: Event
POWer:INRush:GATE<m>:STARt <StartTime>
POWer:INRush:GATE<m>:STOP <StopTime>
Sets the measuring time for the selected gate.
Suffix:
<m>
.
*
Parameters:
<StopTime> Range: 0 to 10
Increment: 0
*RST: 100E-6
Default unit: s
POWer:INRush:GATE<m>:VALue <Value>
Returns the value of the inrush current.
Suffix:
<m>
.
*
Parameters:
<Value> Range: -1000 to 1000
Increment: 0
*RST: 0
Default unit: A
POWer:INRush:MAXCurrent <MaxExpCurr>
Sets the maximum expected current for the vertical scale.
Parameters:
<MaxExpCurr> Range: -1000 to 1000
Increment: 0
*RST: 10
Default unit: A
POWer:INRush:TRIGger <CurrentValue>
Sets the current value for the trigger.
Parameters:
<CurrentValue> Range: -1000 to 1000
Increment: 0
*RST: 1
Default unit: A
Power analysis (option R&S RTE-K31)
