Power analysis (option R&S RTE-K31)
R&S
®
RTE
991User Manual 1326.1032.02 ─ 20
Average
Enables the "Average" method for building the resulting waveform. The average is cal-
culated from the data of the current acquisition and several acquisitions before. The
method reduces random noise and other heterodyne signals. It requires a stable, trig-
gered and periodic signal for correct function. The number of acquisitions for average
calculation is defined with "Average count", and the "Reset mode" defines the restart
condition.
Remote command:
POWer:SLEWrate:AVGDeriv on page 1961
Auto reset mode / Reset mode
Defines when the envelope and average evaluation restarts.
"None"
No restart, the number of acquisitions considered by the waveform
arithmetics is not limited.
"Time"
Restarts the envelope and average calculation after the time defined
in "Reset time".
"Waveforms"
Restarts the envelope and average calculation after a number of
acquired waveforms defined in "Reset waveforms".
Remote command:
ACQuire:ARESet:MODE on page 1961
ACQuire:ARESet:TIME on page 1962
ACQuire:ARESet:COUNt on page 1962
Reset
Forces the immediate restart of the envelope and average calculation for all wave-
forms.
Remote command:
ACQuire:ARESet:IMMediate on page 1115
Optimize scaling
Selects the scaling for the display of the results.
"Autoscale the signals"
Automatically selects the most appropriate scale for the display of the
results.
"Keep present settings"
The present display settings are not changed.
Remote command:
POWer:SLEWrate:AUTO on page 1961
Report comment
In this field you can write a comment that is displayed in the measurement report, for
example, a measurement description.
Execute
Starts the "Slew Rate" measurement.
8
*n
Control loop
