Remote control commands
R&S
®
RTE
1102User Manual 1326.1032.02 ─ 20
DISPlay:SIGNal:LABel:HORizontal:ABSolute:POSition.................................................... 1104
DISPlay:SIGNal:LABel:VERTical:ABSolute:POSition........................................................1104
DISPlay:SIGNal:LABel:HORizontal:RELative:POSition.....................................................1105
DISPlay:SIGNal:LABel:VERTical:RELative:POSition........................................................1105
DISPlay:SIGNal:LABel:FONTsize...................................................................................1105
DISPlay:SIGNal:LABel:ADD <LabelID>, <Source>, <LabelText>, <PositionMode>,
<XPositon>, <YPositon>
Creates a new waveform label for the specified source waveform.
Setting parameters:
<LabelID> String with the label identifier. The <LabelID> and <Source>
parameters identify each label uniquely, so the label ID must be
unique for the given waveform. Note the <LabelID> because it is
not possible to query it, or to read it on the user interface.
<Source> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4 | XY1 | XY2 | XY3 | XY4 |
MRESult1 | MRESult2 | MRESult3 | MRESult4 | MRESult5 |
MRESult6 | MRESult7 | MRESult8 | QUICk | QUICK | SBUS1 |
SBUS2 | SBUS3 | SBUS4 | D0 | D1 | D2 | D3 | D4 | D5 | D6 |
D7 | D8 | D9 | D10 | D11 | D12 | D13 | D14 | D15 | MSOB1 |
MSOB2 | MSOB3 | MSOB4 | TRK1 | TRK2 | TRK3 | TRK4 |
TRK5 | TRK6 | TRK7 | TRK8 | SG1 | SG2 | SG3 | SG4 | SG5 |
SG6 | SG7 | SG8 | SG1TL1 | SG1TL2 | SG2TL1 | SG2TL2 |
SG3TL1 | SG3TL2 | SG4TL1 | SG4TL2 | SG5TL1 | SG5TL2 |
SG6TL1 | SG6TL2 | SG7TL1 | SG7TL2 | SG8TL1 | SG8TL2 |
Z1V1 | Z1V2 | Z1V3 | Z1V4 | Z1I1 | Z1I2 | Z1I3 | Z1I4 | Z2V1 |
Z2V2 | Z2V3 | Z2V4 | Z2I1 | Z2I2 | Z2I3 | Z2I4 | DIFF1 | DIFF2 |
COMMON1 | COMMON2
Waveform to that the label belongs, see Chapter 18.4.1, "Wave-
form suffix", on page 1072.
<LabelText>
String with the label text that is shown on the display
<PositionMode> ABS | REL
ABS
Position in time and voltage values, or in other units depending
on the waveform character. Absolute positions move with the
waveform display when the scales, the vertical position or offset,
or the reference point are changed.
REL
Fixed label position in percent of the screen counting from the
upper left corner.
<XPositon> Horizontal position of the label text. Values, range and unit
depend on the position mode, the waveform position and scal-
ing. For relative position mode, the range is 0 to 100 %.
Instrument setup
