Remote control commands
R&S
®
RTE
1174User Manual 1326.1032.02 ─ 20
TRIGger<m>:RUNT:POLarity <Polarity>
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
Parameters:
<Polarity> POSitive | NEGative | EITHer
See Chapter 18.4.4, "Polarity parameter", on page 1075.
*RST: POSitive
Usage: Asynchronous command
TRIGger<m>:LEVel<n>:RUNT:LOWer
<Level>
TRIGger<m>:LEVel<n>:RUNT:UPPer <Level>
Set the lower and upper voltage thresholds.
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
<n> 1..31
Indicates the trigger source:
1...4 = channel 1...4
5...31 = not available
Parameters:
<Level> Range: -10 to 10
Increment: 1E-3
*RST: Lower = -0.1, upper =0.1
Default unit: V
Usage: Asynchronous command
TRIGger<m>:RUNT:RANGe <Mode>
Defines the time limit of the runt pulse in relation to the TRIGger<m>:RUNT:WIDTh
and TRIGger<m>:RUNT:DELTa settings.
Suffix:
<m>
.
1..3
1 = A-trigger, 2 = B-trigger, 3 = R-trigger
Parameters:
<Mode> ANY | LONGer | SHORter | WITHin | OUTSide
ANY
Triggers on all runts fulfilling the level condition, without time lim-
itation.
LONGer
Triggers on runts longer than the given "Runt width".
Trigger
