Remote control commands
R&S
®
RTE
1188User Manual 1326.1032.02 ─ 20
These are the commands for channel 1, use the similar commands for channels 2, 3,
and 4.
TRIGger<m>:PATTern:MODE........................................................................................1188
TRIGger<m>:PATTern:TIMeout:MODE........................................................................... 1188
TRIGger<m>:PATTern:TIMeout[:TIME]........................................................................... 1189
TRIGger<m>:PATTern:WIDTh:RANGe............................................................................1189
TRIGger<m>:PATTern:WIDTh[:WIDTh]...........................................................................1189
TRIGger<m>:PATTern:WIDTh:DELTa............................................................................. 1190
TRIGger<m>:PATTern:MODE <Mode>
Adds additional time limitation to the pattern definition.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
Parameters:
<Mode> OFF | TIMeout | WIDTh
OFF
No time limitation. The event occurs if the pattern condition is
fulfilled.
TIMeout
Defines how long the result of the pattern condition must be true
or false. The duration of the timeout is defined using
TRIGger<m>:PATTern:TIMeout[:TIME].
WIDTh
Defines a time range for keeping up the true result of the pattern
condition. The range is defined using TRIGger<m>:PATTern:
WIDTh:RANGe.
*RST:
OFF
Usage: Asynchronous command
TRIGger<m>:PATTern:TIMeout:MODE <TimeoutMode>
Defines the condition for the timeout.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
Parameters:
<TimeoutMode> HIGH | LOW
HIGH
The result stays high.
LOW
The result stays low.
*RST: HIGH
Trigger
