Remote control commands
R&S
®
RTE
1402User Manual 1326.1032.02 ─ 20
Example: See Chapter 18.3.5.2, "Exporting waveform data to file",
on page 1061
Usage: Asynchronous command
EXPort:WAVeform:MULTichannel <MltChXpt>
Enables or disables the multichannel export.
If you enable the multichannel export, all active channels are included to the export
data. You can change the export state using the CHANnel<m>:EXPortstate com-
mand.
If multichannel export is disabled, select the waveform to be exported using the
EXPort:WAVeform:SOURce command.
Note that CHANnel<m>[:WAVeform<n>]:DATA[:VALues]? returns the data of all
channels that are selected for export, no matter of the channel suffix.
Parameters:
<MltChXpt> ON | OFF
*RST: OFF
Usage: Asynchronous command
CHANnel<m>:EXPortstate <ExportState>
Includes or excludes the indicated channel in waveform export. The data of channel
waveform 1 is exported.
The commands takes effect if EXPort:WAVeform:MULTichannel is ON.
Suffix:
<m>
.
1..4
Selects the input channel.
Parameters:
<ExportState> ON | OFF
If you enable the multichannel export, the export state of all
active channels is automatically set ON.
*RST: OFF
Usage: Asynchronous command
EXPort:WAVeform:NAME <FileName>
Sets the file name, file format and path to save the waveform to.
See also: Chapter 12.2.1, "Waveform export files", on page 478
Parameters:
<FileName> String with path and file name with extension .xml, .bin, or .csv
Data management
