Parameters:
<SDASource> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4 | D0 | D1 | D2 | D3 | D4 | D5 | D6 |
D7 | D8 | D9 | D10 | D11 | D12 | D13 | D14 | D15
Digital and analog channels cannot be used at the same time for
data and clock lines.
See Chapter 18.4.2, "Waveform parameter", on page 1074
*RST: C1W1
Usage: Asynchronous command
BUS<m>:I2C:SCL:THReshold
<SCLThreshold>
Sets a user-defined threshold value for the clock line.
Alternatively, you can set the threshold according to the signal technology with
BUS<m>:I2C:TECHnology.
Suffix:
<m>
.
1..4
Selects the serial bus.
Parameters:
<SCLThreshold> User-defined clock threshold
Range: -12 to 12
Increment: 0.1
*RST: 0
Default unit: V
BUS<m>:I2C:SDA:THReshold <SDAThreshold>
Sets a user-defined threshold value for the data line.
Alternatively, you can set the threshold according to the signal technology with
BUS<m>:I2C:TECHnology.
Suffix:
<m>
.
1..4
Selects the serial bus.
Parameters:
<SDAThreshold> User-defined data threshold
Range: -12 to 12
Increment: 0.1
*RST: 0
Default unit: V
BUS<m>:I2C:TECHnology <Technology>
Sets the threshold voltage clock and data lines as defined for various signal technolo-
gies.
