Remote control commands
R&S
®
RTE
1565User Manual 1326.1032.02 ─ 20
TRIGger<m>:FLXRay:NUFRame <NullFrame>
Triggers on the null frame indicator bit, a frame without usable data.
Parameters:
<NullFrame> ONE | ZERO | DC
Bit value: 1, 0, or X (don't care)
*RST: DC
TRIGger<m>:FLXRay:SYFRame <SyncFrame>
Triggers on the sync frame used for synchronization of the FlexRay system. Only sync
nodes can send this frame type.
Parameters:
<SyncFrame> ONE | ZERO | DC
Bit value: 1, 0, or X (don't care)
*RST: DC
TRIGger<m>:FLXRay:STFRame <StartupFrame>
Triggers on startup frames used for startup of the network. Only specific start nodes
can send this frame type.
Parameters:
<StartupFrame> ONE | ZERO | DC
Bit value: 1, 0, or X (don't care)
*RST: DC
TRIGger<m>:FLXRay:FCONdition <IdOperator>
Sets the operator to set a frame ID or a frame ID range.
Parameters:
<IdOperator> OFF | ANY | EQUal | NEQual | LTHan | LETHan | GTHan |
GETHan | INRange | OORange
OFF = ANY
The frame ID is not relevant for the trigger condition.
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less or equal than, Greater Than,
Greater or equal than. These conditions require one frame ID to
be set with TRIGger<m>:FLXRay:FMIN.
INRange | OORange
In range, Out of range: Set the minimum and maximum value of
the range with TRIGger<m>:FLXRay:FMIN and TRIGger<m>:
FLXRay:FMAX.
*RST:
EQUal
