Remote control commands
R&S
®
RTE
1715User Manual 1326.1032.02 ─ 20
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
Return values:
<IdentifierType> B4 | B8
B4: standard format, 4 bit
B8: extended format, 8 bit
*RST: B4
Usage: Query only
BUS<m>:SENT:FRAMe<n>:IDValue?
Returns the identifier value of the selected frame.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
Return values:
<IdentifierValue> To set the value format, use FORMat:BPATtern.
The values below – range, increment and reset – are decimal
values.
Range: 0 to 255
Increment: 1
*RST: 0
Usage: Query only
BUS<m>:SENT:FRAMe<n>:NIBBle<o>:STATe?
Returns the state of the specified nibble.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
<o> *
Selects the nibble number.
Protocols
