BUS<m>:CMSB:FRAMe<n>:CELL<o>:BITorder <BitOrder>
Selects in which order the bits of a cell are evaluated, as well as presented in the
results table and honeycomb display.
Suffix:
<m>
.
1..4
<n> *
<o> *
Parameters:
<BitOrder> LSBF | MSBF
LSBF
Least significant bit first, evaluation starts at the LSB
MSBF
Most significant bit first, evaluation starts at the MSB
*RST: MSBF
BUS<m>:CMSB:FRAMe<n>:CELL<o>:CRGB <Color>
Selects a cell's color representation in the honeycomb display.
Suffix:
<m>
.
1..4
<n> *
<o> *
Parameters:
<Color> ARGB value of the color to be used for the table entry.
ARGB=<Opacity(alpha) value><red value><green value><blue
value>, in hexadecimal or decimal format.
Range: 0 to 4294967295
Increment: 1
*RST: 0
BUS<m>:CMSB:EXRBits
Exports the decoded frames as raw bits.
Suffix:
<m>
.
1..4
Usage: Event
BUS<m>:CMSB:FRAMe<n>:CELL<o>:CLMN <Column>
Selects which cell shall be displayed in which result column of the decode table.
