Remote control commands
R&S
®
RTE
1838User Manual 1326.1032.02 ─ 20
Parameters:
<DataMin>
TRIGger<m>:USBPd:DOPerator <Frame>, <Field>, <Operator>
TRIGger<m>:USBPd:FRAMe<n>:FLD<o>:DOPerator <DataOperator>
Sets the operator for the data pattern in the selected field of the selected frame.
Suffix:
<m>
.
1..3
<n> *
Specifies the field number within the frame.
<o> *
Parameters:
<DataOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan |
INRange | OORange
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less than or equal, Greater than,
Greater than or equal. These conditions require one endpoint
value to be set using TRIGger<m>:USBPd:FRAMe<n>:
FLD<o>:DMIN.
INRange | OORange
In range, out of range. These conditions require a range of end-
point values to be set using TRIGger<m>:USBPd:FRAMe<n>:
FLD<o>:DMIN and TRIGger<m>:USBPd:FRAMe<n>:FLD<o>:
DMAX.
*RST:
EQUal
TRIGger<m>:USBPd:IMAX <Frame>, <Field>, <Data>
TRIGger<m>:USBPd:FRAMe<n>:FLD<o>:IMAX <IndexMax>
Sets the end value of an index range if TRIGger<m>:USBPd:FRAMe<n>:FLD<o>:
IOPerator on page 1839 is set to INRange or RANGe.
Suffix:
<m>
.
1..3
<n> *
Specifies the field number within the frame.
<o> *
Parameters:
<IndexMax> Specifies the end value for the index range within the field.
The index range, increment and *RST values depend on the
field type.
Protocols
