Data and file management
R&S
®
RTE
497User Manual 1326.1032.02 ─ 20
For details on waveform save/recall settings, see Chapter 12.2.2, "Waveforms - export
settings", on page 485.
The following procedures are described:
●
"To save a waveform or a part of a waveform to a file" on page 497
●
"To save a waveform using the toolbar icon" on page 497
●
"To export waveform data of a running acquisition" on page 498
●
"To save the history data" on page 317
●
"To load a reference waveform" on page 291
"To save a reference waveform" on page 291
To save a waveform or a part of a waveform to a file
1. Press the [FILE] key.
2. In the "Save" tab, tap the "Waveform" button.
3. Select the waveforms to be saved:
● To save one waveform, tap the "Source" icon and select the waveform.
● To save data of several channels, enable "Multi channel" and select the chan-
nels.
4. In the "Scope" list, select the part of the waveform record to be saved. Zoom, cur-
sor and gate segments require the same setup for the selected waveform before
saving. For "Manual", enter the "Start" and "Stop" time of the section.
5. Check the filename under "Save to file" and change it if needed. Usually, autonam-
ing is used.
6. Check the file format and the "Export format" settings and change them if needed.
7. Tap "Save" to save the waveform data to the specified file.
Tap "Save As" to save the waveform data to a different file or file type. Select the
file from the file selection dialog box.
To save a waveform using the toolbar icon
1. Add the "Save Waveform" icon to the toolbar, see Chapter 3.4.7.2, "Configuring the
toolbar", on page 119.
2. Set the scope, export format, and other parameters in [FILE] > "Waveforms /
Results" > "Waveforms".
3. If necessary, adjust the autonaming pattern and the storage path in [FILE] > "Auto-
naming".
4. To save the waveform data:
a) Tap the "Save Waveform" icon on the toolbar.
b) Tap the waveform to be saved.
If you tap the diagram background, the data of the focused waveform is saved.
Waveform data and results
