TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-11 V2.0, 2007-07

Regs, V2.0

Table 18-4 Address Map of SBCU

Short Name Description Address Access Mode Reset Value

Read Write

System Peripheral Bus Control Unit (SBCU)

– Reserved F000 0100

F000 0104

BE BE –

SBCU_ID SBCU Module

Identification Register

F000 0108

U, SV BE 0000 6AXX

– Reserved F000 010C

BE BE –

SBCU_CON SBCU Control Register F000 0110

U, SV SV 4009 FFFF

– Reserved F000 0114

F000 011C

BE BE –

SBCU_

ECON

SBCU Error Control

Capture Register

F000 0120

U, SV SV 0000 0000

SBCU_

EADD

SBCU Error Address

Capture Register

F000 0124

U, SV SV 0000 0000

SBCU_

EDAT

SBCU Error Data Capture

F000 0128

U, SV SV 0000 0000

– Reserved F000 012C

BE BE –

SBCU_

DBCNTL

SBCU Debug Control

F000 0130

U, SV SV 0000 7003

SBCU_

DBGRNT

SBCU Debug Grant Mask

F000 0134

U, SV SV 0000 FFFF

SBCU_

DBADR1

SBCU Debug Address 1

F000 0138

U, SV SV 0000 0000

SBCU_

DBADR2

SBCU Debug Address 2

F000 013C

U, SV SV 0000 0000

SBCU_

DBBOS

SBCU Debug Bus

Operation Signals

F000 0140

U, SV SV 0000 0000

SBCU_

DBGNTT

SBCU Debug Trapped

Master Register

F000 0144

U, SV BE FFFF FFFF

SBCU_

DBADRT

SBCU Debug Trapped

Address Register

F000 0148

U, SV BE 0000 0000
