TC1796
Peripheral Units (Vol. 2 of 2)
Micro Link Interface (MLI)
User’s Manual 23-140 V2.0, 2007-07
MLI, V2.0
23.5.5.2 Break Signals
The BRKOUT output signals of MLI0 and MLI1 are connected as break input signals to
the Multi Core Break Switch (MCBS) that is a part of the Cerberus on-chip debug control
module. These connections allow MLI0/MLI1 initiated break conditions to be generated
in the Cerberus.
MLI1 SR0 DMA_MLI1SRC0 MLI1 Service Request Node 0 (in DMA)
SR1 DMA_MLI1SRC1 MLI1 Service Request Node 1 (in DMA)
SR2 Not connected
SR3 Not connected
SR4 CH10_REQI14 DMA Channel 10 Request Input 15
CH14_REQI14 DMA Channel 14 Request Input 15
SR5 CH11_REQI6 DMA Channel 11 Request Input 15
CH15_REQI5 DMA Channel 15 Request Input 15
SR6 CH12_REQI5 DMA Channel 12 Request Input 15
CH16_REQI6 DMA Channel 16 Request Input 15
SR7 CH13_REQI5 DMA Channel 13 Request Input 15
CH17_REQI6 DMA Channel 17 Request Input 15
Table 23-14 Service Request Lines and Interconnections of MLI0/MLI1 (cont’d)
Module Service Req.
Output Line
Connected to
Node or DMA
Request Input
Description
