TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-60 V2.0, 2007-07
Ports, V2.0
10.9.2 Port 6 Function Table
Table 10-19 summarizes the I/O control selection functions of each Port 6 line.
Table 10-19 Port 6 Functions
Port
Pin
I/O Pin Functionality Associated Reg./
I/O Line
Port I/O Control Select.
Reg./Bit Field Value
P6.4 I General-purpose input P6_IN.P4 P6_IOCR4.PC4 0XXX
B
SSC1 input (slave mode) MTSR1
O General-purpose output P6_OUT.P4 1X00
B
SSC1 output
(master mode)
MTSR1 1X01
B
Reserved
1)
–1X10
B
1X11
B
P6.5 I General-purpose input P6_IN.P5 P6_IOCR4.PC5 0XXX
B
SSC1 input
(master mode)
MRST1
O General-purpose output P6_OUT.P5 1X00
B
SSC1 output (slave mode) MRST1 1X01
B
Reserved
1)
–1X10
B
1X11
B
P6.6 I General-purpose input P6_IN.P6 P6_IOCR4.PC6 0XXX
B
SSC1 input (slave mode) SCLK1
O General-purpose output P6_OUT.P6 1X00
B
SSC1 output
(master mode)
SCLK1 1X01
B
Reserved
1)
–1X10
B
1X11
B
P6.7 I General-purpose input P6_IN.P7 P6_IOCR4.PC7 0XXX
B
SSC1 input SLSI1
O General-purpose output P6_OUT.P7 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
