TC1796
System Units (Vol. 1 of 2)
Data Memory Unit
User’s Manual 8-10 V2.0, 2007-07
DMU, V2.0
8.7 DMU Registers
Figure 8-4 shows all registers associated with the DMU.
DMU Registers Overview
Figure 8-4 DMU Overlay Control Registers
The complete and detailed address map of the PMU module with its registers is shown
in Table 18-37 on Page 18-118 of this TC1796 System Units (Vol. 1 of 2) User’s Manual.
Table 8-1 Registers Address Space - DMU Registers
Module Base Address End Address Note
DMU F801 0100
H
F801 01FF
H
–
Table 8-2 Registers Overview PMU Overlay Control Registers
Register
1)
Short Name
1) The PMU register short names are extended and referenced in the other parts of the TC1796 User’s Manual
with the module name prefix “PMU_”.
Register Long Name Offset
Address
Description
see
ID Module Identification Register 0008
H
Page 8-11
RABRx Redirected Address Base Register x
(x = 0-15)
0020
H
+
x × C
H
Page 8-13
OTARx Overlay Target Address Register x
(x = 0-15)
0020
H
+
x × C
H
+ 4
Page 8-15
OMASKx Overlay Mask Register x
(x = 0-15)
0020
H
+
x × C
H
+ 8
Page 8-16
SBRCTR Stand-by SRAM Control Register 00E0
H
Page 8-12
MCA05651_mod
ID RABRx
OTARx
OMASKx
Overlay RegistersGeneral/Control
Register
SBRCTR
x = 0-15
To Next Page
