TC1796
Peripheral Units (Vol. 2 of 2)
Asynchronous/Synchronous Serial Interface (ASC)
User’s Manual 19-19 V2.0, 2007-07
ASC, V2.0
19.2 ASC Kernel Registers
This section describes the kernel registers of the ASC module. All ASC kernel register
names described in this section will be referenced in other parts of the TC1796 User’s
Manual by the module name prefix “ASC0_” for the ASC0 interface and “ASC1_” for the
ASC1 interface.
ASC Kernel Register Overview
Figure 19-11 ASC Kernel Registers
The complete and detailed address map of the of the ASC modules is described in
Table 18-8 on Page 18-20 of the TC1796 User’s Manual System Units part (Volume 1).
Table 19-6 Registers Address Space
Module Base Address End Address Note
ASC0 F000 0A00
H
F000 0AFF
H
–
ASC1 F000 0B00
H
F000 0BFF
H
–
Table 19-7 Registers Overview - ASC Kernel Registers
Register
Short Name
Register Long Name Offset
Address
1)
Description
see
PISEL Peripheral Input Select Register 04
H
Page 19-21
ID Module Identification Register 08
H
Page 19-20
CON Control Register 10
H
Page 19-22
BG Baud Rate Timer Reload Register 14
H
Page 19-27
FDV Fractional Divider Register 18
H
Page 19-27
TBUF Transmit Buffer Register 20
H
Page 19-28
MCA5772_mod
CON
BG
TBUF
Control Registers Data Registers
FDV
RBUF
PISEL
WHBCON
Identification
Register
ID
