TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-20 V2.0, 2007-07

Regs, V2.0

Table 18-8 Address Map of ASC0/ASC1

Short Name Description Address Access Mode Reset Value

Read Write

Asynchronous/Synchronous Serial Interface 0 (ASC0)

ASC0_CLC ASC0 Clock Control

F000 0A00

U, SV SV, E 0000 0003

ASC0_

PISEL

ASC0 Peripheral Input

Select Register

F000 0A04

U, SV U, SV 0000 0000

ASC0_ID ASC0 Module

Identification Register

F000 0A08

U, SV BE 0000 44XX

– Reserved F000 0A0C

BE BE –

ASC0_CON ASC0 Control Register F000 0A10

U, SV U, SV 0000 0000

ASC0_BG ASC0 Baud Rate Timer

Reload Register

F000 0A14

U, SV U, SV 0000 0000

ASC0_FDV ASC0 Fractional Divider

F000 0A18

U, SV U, SV 0000 0000

– Reserved F000 0A1C

BE BE –

ASC0_

TBUF

ASC0 Transmit Buffer

F000 0A20

U, SV U, SV 0000 0000

ASC0_

RBUF

ASC0 Receive Buffer

F000 0A24

U, SV U, SV 0000 0000

– Reserved F000 0A28

F000 0A4C

BE BE –

ASC0_

WHBCON

ASC0 Write Hardware

Bits Control Register

F000 0A50

U, SV U, SV 0000 0000

– Reserved F000 0A54

F000 0AEC

BE BE –

ASC0_

TSRC

ASC0 Transmit Interrupt

Service Req. Control Reg.

F000 0AF0

U, SV U, SV 0000 0000

ASC0_

RSRC

ASC0 Receive Interrupt

Service Req. Control Reg.

F000 0AF4

U, SV U, SV 0000 0000

ASC0_

ESRC

ASC0 Error Interrupt

Service Req. Control Reg.

F000 0AF8

U, SV U, SV 0000 0000

ASC0_

TBSRC

ASC0 Transmit Buffer

Interrupt Service Request

Control Register

F000 0AFC

U, SV U, SV 0000 0000
