TC1796

System Units (Vol. 1 of 2)

Peripheral Control Processor (PCP)

User’s Manual 11-87 V2.0, 2007-07

PCP, V2.0

11.11.13 DINIT, Divide Initialization Instruction

This section describes the DINIT instruction of the PCP.

DINIT Syntax DINIT <R0>, Rb, Ra

Description Initialize Divide logic ready for divide sequence (Rb / Ra) and

Clear R0. If value of Ra is 0 then set V (to flag divide by 0

error); otherwise clear V. If value of Rb is 0 and value of Ra is

not 0 then set Z (to flag a zero result); otherwise clear Z.

Operation R0 = 0

Flags Z, V
