TC1796
Peripheral Units (Vol. 2 of 2)
Micro Link Interface (MLI)
User’s Manual 23-146 V2.0, 2007-07
MLI, V2.0
23.5.7 MLI0/MLI1 Transfer Window Address Maps
In the TC1796, the transfer windows for the MLI0 and MLI1 modules are located in the
address ranges as identified in Table 23-18.
Table 23-18 MLI0/MLI1 Transfer Windows
Module Window Type Pipe Address Range
MLI0 Small Transfer Window Pipe 0 F01E 0000
H
to F01E 1FFF
H
Pipe 1 F01E 2000
H
to F01E 3FFF
H
Pipe 2 F01E 4000
H
to F01E 5FFF
H
Pipe 3 F01E 6000
H
to F01E 7FFF
H
Large Transfer Window Pipe 0 F020 0000
H
to F020 FFFF
H
Pipe 1 F021 0000
H
to F021 FFFF
H
Pipe 2 F022 0000
H
to F022 FFFF
H
Pipe 3 F023 0000
H
to F023 FFFF
H
MLI1 Small Transfer Window Pipe 0 F01E 8000
H
to F01E 9FFF
H
Pipe 1 F01E A000
H
to F01E BFFF
H
Pipe 2 F01E C000
H
to F01E DFFF
H
Pipe 3 F01E E000
H
to F01E FFFF
H
Large Transfer Window Pipe 0 F024 0000
H
to F024 FFFF
H
Pipe 1 F025 0000
H
to F025 FFFF
H
Pipe 2 F026 0000
H
to F026 FFFF
H
Pipe 3 F027 0000
H
to F027 FFFF
H
