TC1796

System Units (Vol. 1 of 2)

CPU Subsystem

User’s Manual 2-46 V2.0, 2007-07

CPU, V2.0

2.7.1.3 MAC Instruction Timings

Each instruction is single issued.

Table 2-12 MAC Instruction Timing

Instruction Result

Latency

Repeat

Rate

Instruction Result

Latency

Repeat

Rate

IP Arithmetic Instructions

MADD 32MSUB 32

MADD.U 32MSUB.U 32

MADDS 32MSUBS 32

MADDS.U 32MSUBS.U 32

MADD.H 21MSUB.H 21

MADD.Q 2/3 1/2 MSUB.Q 2/3 1/2

MADDM.H 21MSUBM.H 21

MADDMS.H 21MSUBMS.H 21

MADDR.H 21MSUBR.H 21

MADDR.Q 21MSUBR.Q 21

MADDRS.H 21MSUBRS.H 21

MADDRS.Q 21MSUBRS.Q 21

MADDS.H 21MSUBS.H 21

MADDS.Q 2/3 1/2 MSUBS.Q 2/3 1/2

MADDSU.H 21MSUBAD.H 21

MADDSUM.H 21MSUBADM.H 21

MADDSUMS.H 21MSUBADMS.H 21

MADDSUR.H 21MSUBADR.H 21

MADDSURS.H 21MSUBADRS.H 21

MADDSUS.H 21MSUBADS.H 21
