TC1796

Peripheral Units (Vol. 2 of 2)

Fast Analog-to-Digital Converter (FADC)

User’s Manual 26-29 V2.0, 2007-07

FADC, V2.0

26.2.1 Identification Register

The Module Identification Register ID contains read-only information about the FADC

module version.

Module Identification Register (08

) Reset Value: 0027 C0XX

31 16 15 8 7 0

MODNUM MODTYPE MODREV

rrr

Field Bits Type Description

MODREV [7:0] r Module Revision Number

MODREV defines the module revision number. The value

of a module revision starts with 01

(first revision).

MODTYPE [15:8] r Module Type

This bit field defines the module as a 32-bit module: C0

MODNUM [31:16] r Module Number Value

This bit field defines the module identification number for

the FADC: 0027
