22.9.4 Port and I/O Line Control
The interconnections between the MultiCAN module and the port I/O lines are controlled
in the port logic. Additionally to the port input selection, the following port control
operations must be executed:
• Input/output function selection (IOCR registers)
• Pad driver characteristics selection for the outputs (PDR registers)
22.9.4.1 Input/Output Function Selection in Ports
The port input/output control registers contain the bit fields that select the digital output
and input driver characteristics such as pull-up/down devices, port direction
(input/output), open-drain, and alternate output selections. The I/O lines for the MultiCAN
module are controlled by the port input/output control registers P6_IOCR8 and
P6_OCR12.
Table 22-16 shows how bits and bit fields must be programmed for the required I/O
functionality of the CAN I/O lines.
Table 22-16 MultiCAN I/O Control Selection and Setup
Module Port Lines Input/Output Control Register
Bits
1)
1) Possible PCx bit field combinations see Table 22-17.
I/O
CAN P6.8 / RXDCAN0 P6_IOCR8.PC8 = 0XXX
B
Input
P6.9 / TXDCAN0 P6_IOCR8.PC9 = 1X01
B
Output
P6.10 / RXDCAN1 P6_IOCR8.PC10 = 0XXX
B
Input
P6.11 / TXDCAN1 P6_IOCR8.PC11 = 1X01
B
Output
P6.12 / RXDCAN2 P6_IOCR12.PC12 = 0XXX
B
Input
P6.13 / TXDCAN2 P6_IOCR12.PC13 = 1X01
B
Output
P6.14 / RXDCAN3 P6_IOCR12.PC14 = 0XXX
B
Input
P6.15 / TXDCAN3 P6_IOCR12.PC15 = 1X01
B
Output
