TC1796
Peripheral Units (Vol. 2 of 2)
Synchronous Serial Interface (SSC)
User’s Manual 20-27 V2.0, 2007-07
SSC, V2.1
20.2 SSC Kernel Registers
This section describes the kernel registers of the SSC module. All SSC kernel register
names described in this section will be referenced in other parts of the TC1796 User’s
Manual by the module name prefix “SSC0_” for the SSC0 interface and “SSC1_” for the
SSC1 interface.
SSC Kernel Register Overview
Figure 20-15 SSC Kernel Registers
The complete and detailed address map of the SSC modules is described in
Table 18-27 on Page 18-81 of the TC1796 User’s Manual System Units part (Volume 1).
Table 20-2 Registers Address Space - SSC Kernel Registers
Module Base Address End Address Note
SSC0 F010 0100
H
F010 01FF
H
–
SSC1 F010 0200
H
F010 02FF
H
–
Table 20-3 Registers Overview - SSC Kernel Registers
Register
Short Name
Register Long Name Offset
Address
1)
Description
see
PISEL Port Input Select Register 04
H
Page 20-30
ID Module Identification Register 08
H
Page 20-29
ID
CON
BR
MCA05790_mod
TB
Control Registers Data Registers
RB
STAT
EFM
SSOC
SSOTC
RXFCON
TXFCON
FSTAT
PISEL
Identification
Register
ID
