TC1796

System Units (Vol. 1 of 2)

CPU Subsystem

User’s Manual 2-29 V2.0, 2007-07

CPU, V2.0

2.5.3.3 PMI Control Register 1

PMI_CON1

PMI Control Register 1 (F87FFD14

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

INV

rrw

Field Bits Type Description

CCINV 0rwCode Cache Invalidate

Normal code cache (ICACHE) operation

All cache lines are invalidated

As long as CCINV is set, all instruction fetch

accesses generate a cache refill. It is recommended

that CCINV be kept set until ICACHE coherency is

guaranteed.

0 [31:1] r Reserved

Returns 0 when read; should be written with 0.
