TC1796

Peripheral Units (Vol. 2 of 2)

Micro Second Channel (MSC)

User’s Manual 21-64 V2.0, 2007-07

MSC, V2.0

21.3.2 MSC0/MSC1 Module-Related External Registers

Figure 21-30 summarizes the module-related external registers which are required for

programming of MSC0 and MSC1 (see also Figure 21-28 for the module kernel specific

registers). These registers are described in the following sections.

Figure 21-30 MSC Implementation-specific Special Function Registers

MCA05824

MSC0_SRCx

Interrupt Registers

P5_IOCR4

Port RegistersClock Control

Registers

MSC0_CLC

x = 0, 1

MSC1_CLC

MSC0_FDR

MSC1_FDR

MSC1_SRCxP5_PDR

P9_IOCR0

P9_IOCR4

P9_IOCR8

P9_PDR
