TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-27 V2.0, 2007-07
Ports, V2.0
10.4.2 Port 1 Function Table
Table 10-9 summarizes the I/O control selection functions of each Port 1 line.
Table 10-9 Port 1 Functions
Port
Pin
I/O Pin Functionality Associated Reg./
I/O Line
Port I/O Control Select.
Reg./Bit Field Value
P1.0 I General-purpose input P1_IN.P0 P1_IOCR0.PC0 0XXX
B
SCU input REQ0
O General-purpose output P1_OUT.P0 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
P1.1 I General-purpose input P1_IN.P1 P1_IOCR0.PC1 0XXX
B
REQ1
O General-purpose output P1_OUT.P1 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
P1.2 I General-purpose input P1_IN.P2 P1_IOCR0.PC2 0XXX
B
REQ2
O General-purpose output P1_OUT.P2 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
P1.3 I General-purpose input P1_IN.P3 P1_IOCR0.PC3 0XXX
B
SCU input REQ3
TTCAN input ECTT1
MLI0 input TREADY0B
O General-purpose output P1_OUT.P3 1X00
B
Reserved
1)
–1X01
B
1X10
B
1X11
B
