Page #1749 background imageLoading...
Page #1749 background image
TC1796
Peripheral Units (Vol. 2 of 2)
General Purpose Timer Array (GPTA)
User’s Manual 24-94 V2.0, 2007-07
GPTA, V2.0
24.2.4.1 FPC Input Line Selection
As shown on Page 24-10, each FPC cell can be connected to one out of four input lines
SINk[3:0], to the GPTA module clock f
GPTA
, or to the output of the preceding FPC. In total,
24 input lines out of the 56 input lines IN[55:00] from the I/O groups are connected (not
programmable) with the FPCk inputs. The FPCk input line selection is controlled by the
FPCCTRk.IPS bit fields. Table 24-23 shows the FPC port pin connections.
Table 24-9 FPC Input Line Assignments
FPC Control Register Bit Field IPS Selected Input Pin
FPCCTR0 000
B
IN0
IN12 001
B
010
B
IN24
011
B
IN36
FPCCTR1 000
B
IN2
001
B
IN14
010
B
IN26
011
B
IN38
FPCCTR2 000
B
IN4
001
B
IN16
010
B
IN28
011
B
IN40
FPCCTR3 000
B
IN6
001
B
IN18
010
B
IN30
011
B
IN42
FPCCTR4 000
B
IN8
001
B
IN20
010
B
IN32
011
B
IN44
FPCCTR5 000
B
IN10
001
B
IN22
010
B
IN34
011
B
IN46
