TC1796
System Units (Vol. 1 of 2)
On-Chip System Buses and Bus Bridges
User’s Manual 6-34 V2.0, 2007-07
Buses, V2.0
6.5.5 SBCU and RBCU Registers
The registers shown in Figure 6-13 are available for the SBCU.
SBCU Registers Overview
Figure 6-13 SBCU Registers
The complete and detailed address maps of SBCU/RBCU are described in
Table 18-4/Table 18-26 on Page 18-11/Page 18-79 of this TC1796 System Units (Vol.
1 of 2) User’s Manual.
Table 6-13 Registers Address Space
Module Base Address End Address Note
SBCU F000 0100
H
F000 01FF
H
–
RBCU F010 0000
H
F010 00FF
H
–
Table 6-14 Registers Overview - SBCU Registers
Register
Short Name
1)
Register Long Name Offset
Address
Description
see
xBCU_ID xBCU Module Identification Register 08
H
Page 6-36
xBCU_CON xBCU Control Register 10
H
Page 6-37
xBCU_ECON xBCU Error Control Capture Register 20
H
Page 6-39
xBCU_EADD xBCU Error Address Capture Register 24
H
Page 6-41
xBCU_EDAT xBCU Error Data Capture Register 28
H
Page 6-41
xBCU_DBCNTL xBCU Debug Control Register 30
H
Page 6-42
MCA05640_mod
xBCU_CON
Control Register Interrupt RegistersAddress/Data
Register
xBCU_ECON
xBCU_EADD
xBCU_SRC
xBCU_EDAT
Debug Registers
xBCU_DBCNTL
xBCU_DBGRNT
xBCU_DBADR1
xBCU_DBADR2
xBCU_DBBOS
x = “S“ for SBCU
x = “R“ for RBCU
xBCU_DBGNTT
xBCU_DBADRT
xBCU_DBBOST
Module Identification
Register
xBCU_ID
