TC1796
System Units (Vol. 1 of 2)
On-Chip System Buses and Bus Bridges
User’s Manual 6-41 V2.0, 2007-07
Buses, V2.0
SBCU_EADD
SBCU Error Address Capture Register (24
H
) Reset Value: 0000 0000
H
RBCU_EADD
RBCU Error Address Capture Register (24
H
) Reset Value: 0000 0000
H
31 0
FPIADR
rwh
Field Bits Type Description
FPIADR [31:0] rwh Captured FPI Bus Address
This bit field holds the 32-bit FPI Bus address that has
been captured at an FPI Bus error. Note that if multiple
bus errors occurred, only the address of the first bus
error is captured.
SBCU_EDAT
SBCU Error Data Capture Register (28
H
) Reset Value: 0000 0000
H
RBCU_EDAT
RBCU Error Data Capture Register (28
H
) Reset Value: 0000 0000
H
31 0
FPIDAT
rwh
Field Bits Type Description
FPIDAT [31:0] rwh Captured FPI Bus Address
This bit field holds the 32-bit FPI Bus data that has
been captured at an FPI Bus error. Note that if multiple
bus errors occurred, only the data of the first bus error
is captured.
