Fast Analog-to-Digital Converter (FADC)
User’s Manual 26-41 V2.0, 2007-07
FADC, V2.0
26.2.3 Channel Registers
The Channel x Configuration Register CFGRx contains the bits for the selection of the
trigger source, the gating source, and other channel settings of channel x.
CFGRx (x = 0-3)
Channel x Configuration Register (20
H
+x*4
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
IEN 0 INP 0 CTREL
rw r rw r rw
1514131211109876543210
0 CTF CTM TM GM TSEL GSEL
rrwrwrwrwrw rw
Field Bits Type Description
GSEL [2:0] rw Gating Selection
This bit field selects the gating source input signal for
channel x.
000
B
Gating source input signal GS0 selected
001
B
Gating source input signal GS1 selected
010
B
Gating source input signal GS2 selected
011
B
Gating source input signal GS3 selected
100
B
Gating source input signal GS4 selected
101
B
Gating source input signal GS5 selected
110
B
Gating source input signal GS6 selected
111
B
Gating source input signal GS7 selected
TSEL [5:3] rw Trigger Selection
This bit field selects the trigger source input signal for
channel x.
000
B
Trigger source input signal TS0 selected
001
B
Trigger source input signal TS1 selected
010
B
Trigger source input signal TS2 selected
011
B
Trigger source input signal TS3 selected
100
B
Trigger source input signal TS4 selected
101
B
Trigger source input signal TS5 selected
110
B
Trigger source input signal TS6 selected
111
B
Trigger source input signal TS7 selected
