Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-78 V2.0, 2007-07
ADC, V2.0
25.2.7 Other Control/Status Registers
AP
Arbitration Participation Register (084
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
r
1514131211109876543210
0CHPTP0EXP
SW
0P
0QPASP
r rwh rwh r rwh rwh r rwh rwh
Field Bits Type Description
ASP 0rwhAuto-Scan Arbitration Participation
0
B
Source does not participate in arbitration
1
B
Source participates in arbitration
QP 1rwhQueue Arbitration Participation
0
B
Source does not participate in arbitration
1
B
Source participates in arbitration
SW0P 3rwhSoftware SW0 Arbitration Participation Flag
0
B
Source does not participate in arbitration
1
B
Source participates in arbitration
EXP 4rwhExternal Event Arbitration Participation Flag
0
B
Source does not participate in arbitration
1
B
Source participates in arbitration
TP 6rwhTimer Arbitration Participation Flag
0
B
Source does not participate in arbitration
1
B
Source participates in arbitration
CHP 7rwhChannel Injection Arbitration Participation Flag
0
B
Source does not participate in arbitration
1
B
Source participates in arbitration
0 2, 5,
[31:8]
r Reserved
Read as 0; should be written with 0.
