Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-79 V2.0, 2007-07
ADC, V2.0
SAL
Source Arbitration Level Register (088
H
) Reset Value: 0103 4067
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0 SALCHIN 0 SALT 0 SALEXT
rrwrrw r rw
1514131211109876543210
0 SALSW0 0 SALQ 0 SALAS
rrw r rwrrw
Field Bits Type Description
SALAS [2:0] rw Auto-Scan Source Arbitration Level
000
B
Highest priority for arbitration selected
111
B
Lowest priority for arbitration selected
SALQ [6:4] rw Queue Source Arbitration Level
000
B
Highest priority for arbitration selected
111
B
Lowest priority for arbitration selected
SALSW0 [14:12] rw Software Source Arbitration Level
000
B
Highest priority for arbitration selected
111
B
Lowest priority for arbitration selected
SALEXT [18:16] rw External Event Source Arbitration Level
000
B
Highest priority for arbitration selected
111
B
Lowest priority for arbitration selected
SALT [26:24] rw Timer Source Arbitration Level
000
B
Highest priority for arbitration selected
111
B
Lowest priority for arbitration selected
SALCHIN [30:28] rw Channel Injection Source Arbitration Level
000
B
Highest priority for arbitration selected
111
B
Lowest priority for arbitration selected
0 3, 15,
27,31,
[11:7],
[23:19]
r Reserved
Read as 0; should be written with 0.
