TC1796

Peripheral Units (Vol. 2 of 2)

Analog-to-Digital Converter (ADC)

User’s Manual 25-80 V2.0, 2007-07

ADC, V2.0

LCCONx (x = 0-3)

Limit Check Control Register x (100

+x*4) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

0 BOUNDARY

rrw

Field Bits Type Description

BOUNDARY [11:0] rw Boundary for Limit Checks

This bit field contains the boundary value used for

limit checking. The relevant bits of this bit field for

the different resolutions are:

8-bit: BOUNDARY[11:4]

10-bit: BOUNDARY[11:2]

12-bit: BOUNDARY[11:0]

Unused bits should be written with 0.

0 [31:12] r Reserved

Read as 0; should be written with 0.
