TC1796
System Units (Vol. 1 of 2)
Peripheral Control Processor (PCP)
User’s Manual 11-101 V2.0, 2007-07
PCP, V2.0
11.11.32 SET, Set Bit
This section describes the SET bit instruction of the PCP.
11.11.33 SHL, Shift Left
This section describes the SHL instruction of the PCP.
SET Syntax SET Ra, #imm5
Description Set bit imm5 of register Ra to 1.
Operation R[a][imm5] = 1
Flags None
SET.F Syntax SET.F [Ra], #imm5, Size
Description Set bit imm5 of the address location specified through the
contents of register Ra to 1. This instruction is executed using
a locked read-modify-write FPI Bus transaction.
Operation FPI[(R[a])][imm5] = 1
Flags None
SHL Syntax SHL Ra, #imm5
Description Shift the contents of register Ra to the left by the number of
bit positions specified through the 5-bit value imm5. The
values allowed for imm5 are 1, 2, 4 and 8. The carry flag,
R7.C, is set to the last bit shifted out of bit 31 of register Ra.
Zeros are shifted in from right.
Operation R[a] = R[a] << imm5; imm5 = 1, 2, 4, 8
R7_C = last bit shifted out of R[a]
Flags N, Z, C
