TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-64 V2.0, 2007-07
Ports, V2.0
10.9.3.4 Port 6 Pad Driver Mode Register and Pad Classes
The Port 6 pad driver mode register contains three bit fields that determine the pad driver
mode (output driver strength and slew rate) of Port 6 line groups. The Port 6 port lines
are all class A2 pads (see also Figure 10-10).
P6_PDR
Port 6 Pad Driver Mode Register (40
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0 PDCAN23 0 PDCAN01 0 PDSSC1 0 0
rrwrrwrrwrrw
1514131211109876543210
0
r
Field Bits Type Description
PDSSC1 [22:20] rw Pad Driver Mode for P6.[7:4]
(Class A2 pads; for coding see Page 10-11)
PDCAN01 [26:24] rw Pad Driver Mode for P6.[11:8]
(Class A2 pads; for coding see Page 10-11)
PDCAN23 [30:28] rw Pad Driver Mode for P6.[15:12]
(Class A2 pads; for coding see Page 10-11)
0 [18:16] rw Reserved
Read as 000
B
after reset; returns value that was
written.
0 [15:0],
19, 23,
27, 31
r Reserved
Read as 0; should be written with 0.
